Digital Loop Impedance & PSC/ PFC Tester 0~500VDC , Loop Imp L-PE 0.20Ω~9999Ω (Hi Amp & No-Trip) , Freq:45Hz~65Hz , LCD Display , RE (Loop Method) 0.20Ω~9999Ω , PSC/PFC Range 0~2kA , Bluetooth 4.0 , 50V~500VAC , L-N Line Res 0.20Ω~9999Ω , 200x95x50mm
Digital Loop Impedance & PSC/ PFC Tester
Features
- Two types of Earth Loop Impedance tests including Non-Trip & Trip Hi-Amp
- Automatically display the wiring status as well as test results
- Smart wiring indicators that visual alerts for reversed wiring and socket wiring status
- Simultaneous display of loop impedance, PSC/PFC and RE
- Automatic AC/DC Voltage Detection up to 500V
- Phase rotation test ensures correct phase sequence in three-phase systems
- Auto lock-out feature prevents damage from overheating
- Bluetooth allows for seamless data transfer and monitoring
- Double moulded rubber housing for protection in harsh environments
Specifications
- Loop Impedance L-PE-0.20Ω - 9999Ω
(Hi Amp & No-Trip)
- RE (Loop Method)-0.20Ω - 9999Ω
- L-N Line Resistance- 0.20Ω - 9999Ω
- PSC/PFC Range-0 - 2kA
- AC Voltage-50V - 500V
- DC Voltage-0V - 500V
- Frequency-45Hz - 65Hz
- Bluetooth-4.0
- Display-LCD Display
- Batteries-6 x AA
- Dimensions-200 x 95 x 50mm
- Weight-700g
Downloads
Additional Information
| Device |
Tester |
| Type |
0~500VDC |
