• H.265+/H.265 video compression
• Supports Full-channel AI-Coding
• Supports HDCVI/AHD/TVI/CVBS/IP video inputs
• Max 18 channels IP camera inputs, each channel up to 6MP; Max 64 Mbps Incoming Bandwidth
• Long transmission distance over coax cable
• Up to 8 channels video stream (analog channel) SMD Plus

System

• Main Processor : Industrial-grade processor
• Operating System : Embedded Linux
• Operating Interface : Web; Local GUI

SMD Plus

• SMD Plus by Recorder : 8-channel: Secondary filtering for human and motor vehicle , reducing false alarms caused by leaves, rain and
  lighting condition change

Audio and Video

• Analog Camera Input : 16 channels, BNC: adaptive access by default; HDCVI,
  AHD, TVI and CVBS access can be configured.

Camera Input

• CVI: 1080p@ 25/30 fps, 720p@25/30 fps
• TVI: 1080p@ 25/30 fps, 720p@25/30 fps
• AHD: 1080p@ 25/30 fps, 720p@25/30 fps
• CVBS: PAL/NTSC

IP Camera Input

• Up to 18 channels of IPC access
  2 IP channels by default + 16 channels (analog channels
  are converted to IP channels)
  incoming bandwidth: 64 Mbps, recording bandwidth: 64
  Mbps and outgoing bandwidth: 64 Mbps
  *After IP channels are added beyond the existing
  channels, the AI Function (SMD) will be disabled.
• Encoding Capacity
  • Main Stream: the 1st channel 1080N/720p (1 fps–25/30 fps), others
    1080N/720p (1 fps–15 fps); 960H/D1/CIF (1 fps–25/30
    fps)
  • Sub steram: CIF (1 fps–7 fps)
• Dual-stream : Yes
• Video Bit Rate : 32 kbps–6144 kbps
• Audio Sampling : 8 kHz, 16 bit
• Audio Bit Rate : 64 kbps
• Video Output : 1 HDMI, 1 VGA, HDMI/VGA: 1920 × 1080, 1280 × 1024, 1280 × 720
• Multi-screen Display : 1/4/8/9/16
• Third-party Camera Access : ONVIF; RTSP; Panasonic; Sony; Axis; Arecont; Pelco;
  Canon; Samsung

Compression Standard

• Video Compression : AI Coding; H.265+; H.265; H.264+; H.264
• Audio Compression : G.711a; G.711u; PCM

Network

• Network Protocol : HTTP; HTTPS; TCP/IP; IPv4; RTSP; UDP; SMTP; NTP; DHCP; DNS; DDNS; P2P
• Mobile Phone Access : iOS; Android
• Interoperability : ONVIF 21.06; CGI Conformant
• Browser
  • Chrome
  • IE9 or later
  • Firefox
• Network Mode : Single-address mode
• Recording Playback
• Record Mode : General, motion detection, alarm
• Recording Playback : 1/4/9/16
• Backup Method : USB device and network
• Playback Mode : Instant playback, general playback, event playback, tag playback

Alarm

• General Alarm : Motion detection, video loss, tampering
• Anomaly Alarm : No disk, disk error, low space, offline, ip conflict, MAC conflict
• Alarm Linkage : Record, snapshot (panoramic), IPC external alarm output, access controller, voice prompt, buzzer, log, preset, email

Ports

• Audio Input
  • 1-channel RCA
  • 16-channel BNC (Coaxial Audio)
• Audio Output : 1-channel RCA
• Two-way Talk : Yes (share the same audio input with the first channel)
• HDD Interface : 1 SATA port, up to 16 TB. The maximum HDD capacity varies with environment temperature
• RS-485 : 1 port, for PTZ control
• USB : 2 USB ports (USB 2.0)
• HDMI : 1
• VGA : 1
• Network Port : 1 (10/100 Mbps Ethernet port, RJ-45)

General

• Power Supply : 12 VDC, 2 A
• Power Consumption : <10 W
• Net Weight : 1.042 kg (3.00 lb)
• Gross Weight : 1.48 kg (3.26 lb)
• Product Dimensions : 260.0 mm × 237.9 mm × 47.6 mm (10.24'' × 9.37'' × 1.87'') (W × D × H)
• Packaging Dimensions : 333.0mm × 315.0mm × 89.0mm(13.11" × 12.40" × 3.50") (W× D × H)
• Operating Temperature : –10 °C to +55 °C (+14 °F to +131 °F)
• Operating Humidity : 0%–90% (RH)
• Installation : Desktop

1. Datasheet - DHA XVR4116HS-I
