SKU: DHA IPC-HFW3441DG-AS4GEAUB 2.8MM
BRAND: Dahua
In Stock
R 4,818.50 (inc VAT)
R 4,190.00 (ex VAT)
Collections: Dahua, New Arrivals, Security, Access Control & Surveillance
Type: CCTV Products & Accessories
Category: Battery Wifi Camera, Bullet Cameras, New
Camera |
|||||
Image Sensor |
1/3" CMOS |
||||
Max. Resolution |
2688 (H) × 1520 (V) |
||||
ROM |
128MB |
||||
RAM |
256MB |
||||
Scanning System |
Progressive |
||||
Electronic Shutter Speed |
Auto/Manual 1/3 s–1/100,000 s |
||||
Min. Illumination |
0.01 Lux@F1.6 (Color,30IRE) 0.001 Lux@F1.6 (B/W,30IRE) 0 lux (Illuminator on) |
||||
S/N Ratio |
>56 dB |
||||
Illumination Distance |
IR: 50 m (164.04 ft) |
||||
Illuminator On/Off Control |
Auto;Manual |
||||
Illuminator Number |
1 (IR LED); 1 (Warm light) |
||||
Angle Adjustment |
Pan: 0°–360° Tilt: –60°–0° Rotation: 0°–360° |
||||
PIR Sensor Distance |
10 m (the height of device is 2.5 m, placed horizontally) |
||||
Lens |
|||||
Lens Type |
Fixed-focal |
||||
Lens Mount |
M12 |
||||
Focal Length |
2.8 mm |
||||
Max. Aperture |
2.8 mm: F1.6 |
||||
Field of View |
2.8 mm: H: 102°; V: 54°; D:121° |
||||
Iris Control |
Fixed |
||||
Close Focus Distance |
2.8 mm: 0.9 m (2.95 ft) |
||||
DORI Distance |
Lens |
Detect |
Observe |
Recognize |
Identify |
2.8 mm |
63.6 m (208.66 ft) |
25.4 m (83.33 ft) |
12.7 m (41.67 ft) |
6.4 m (21.00 ft) |
|
DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool. |
|||||
Video |
|||||
Video Compression |
H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream) |
||||
Video Frame Rate |
Main stream: 2688 × 1520 @(1–25/30 fps ) sub stream: 704 × 576 @ (1–25 fps)/704 × 480 @ (1–30 fps) |
||||
Stream Capability |
2 streams |
||||
Resolution |
4M (2688 × 1520); 4M (2560 × 1440); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 ×960 ); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240) |
||||
Bit Rate Control |
CBR/VBR |
||||
Video Bit Rate |
H.264: 32 kbps–8192 kbps |
||||
Day/Night |
Auto(ICR)/Color/B/W |
||||
BLC |
Yes |
||||
HLC |
Yes |
||||
WDR |
120 dB |
||||
Scene Self-adaptation (SSA) |
Yes |
||||
White Balance |
Auto; natural; street lamp; outdoor; manual; regional custom |
||||
Gain Control |
Auto |
||||
Noise Reduction |
3D NR |
||||
Motion Detection |
OFF/ON (4 areas, rectangular) |
||||
Region of Interest (RoI) |
Yes (4 areas) |
||||
Smart Illumination |
Yes |
||||
Mirror |
Yes |
||||
Privacy Masking |
4 areas |
||||
Audio |
|||||
Built-in MIC |
Yes |
||||
Built-in Speaker |
Yes |
||||
Audio Compression |
G.711a;G.711Mu; G.726; PCM |
||||
Alarm |
|||||
Alarm Event |
SD card error; SD card full; IP conflict; illegal access; motion detection; video tampering; Scene Changing; audio detection; security exception; PIR alarm; external alarm; low battery alarm; light alarm; sound alarm |
||||
Network |
|||||
Network Port |
RJ-45 (10/100 Base-T) |
||||
Frequency |
LTE FDD:B1/3/5/7/8/20/28 |
||||
SDK and API |
Yes |
||||
Cyber Security |
Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade |
||||
Network Protocol |
IPv4; IPv6; HTTP;TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP; P2P |
||||
Interoperability |
ONVIF (Profile S/Profile G); CGI |
||||
User/Host |
20 (Total bandwidth: 80 M) |
||||
Storage |
Bulit in eMMC (8 GB); FTP;SFTP; Micro SD card (support max. 256 GB); NAS |
||||
Browser |
IE |
||||
Management Software |
DSS; DMSS |
||||
Mobile Client |
iOS; Android |
||||
Certification |
|||||
Certifications |
CE-LVD: EN62368-1; CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU; CE-RED: Radio Equipment Directive 2014/53/EU; FCC: 47 CFR FCC Part 15; Subpart B |
||||
Port |
|||||
Audio Input |
1 channel (RCA port) |
||||
Audio Output |
1 channel (RCA port) |
||||
Alarm Input |
1 channel in: 5 mA 3–5 VDC |
||||
Alarm Output |
1 channel out: 300 mA 12 VDC |
||||
RS-485 |
1 (Only report the information of solar battery, such as power and battery level) |
||||
Power |
|||||
Power Supply |
12 VDC |
||||
Power Consumption |
Sleep Mode: 0.03 W General Mode: 4 W Power Saving Mode: 2 W Max. (4G pulling stream+IR+speaker+warning light): 7.5 W |
||||
Environment |
|||||
Operating Temperature |
–40 °C to +60 °C (–40 °F to +140 °F) |
||||
Operating Humidity |
≤ 95% |
||||
Storage Temperature |
–40 °C to +60 °C (–40 °F to +140 °F) |
||||
Protection |
IP67 |
||||
Structure |
|||||
Casing |
Metal + plastic |
||||
Product Dimensions |
132 mm × 219 mm×179 mm (5.20" × 8.62" × 7.05") (L × W × H) |
||||
Packaging Dimensions |
280 mm × 239 mm × 146 mm (11.02" × 9.41" × 5.75") (L × W × H) |
||||
Net Weight |
680 g (1.50 lb) |
||||
Gross Weight |
1180 g (2.60 lb) |
Device | Camera |
Type | WizSense | 4G | Bullet | Network |
