• Nominal Voltage : 12V
• Rated Capacity : 7Ah
• Dimensions
  • Length : 151mm
  • Width : 65mm
  • Height : 95mm
  • Total Height : 101mm
• Appoximate Weight : 1.95kg

Characteristics

• Capacity 77°F(25°C)
• 20hour rate (0.35 A) : 7Ah
• 10hour rate (0.65 A) : 5.85Ah
• 5hour rate (1.12 A) : 5.52Ah
• 1hour rate (4.76 A) : 3.90Ah
• 15min rate (13.2A) : 2.93Ah
• Internal Resistance
  • Full Charged, 77°F(25°C) : 65mΩ
• Affected By Temperature (20hr Rate)
  • 104°F(40°C) : 102%
  • 77°F(25°C) : 100%
  • 32°F(0°C) : 85%
  • 5°F(-15°C) : 65%
• Self-Discharge 68°F
  • Capacity after 3 month storage : 90%
  • Capacity after 6 month storage : 80%
  • Capacity after 12 month storag : 60%
• Max. Discharge Current 77°F((25°C) : 97.5A(5s)
• Terminal : F1
• Charge (Constant Voltage, 25°C)
  • Cycle : 14.5V~14.9V(-24mV/°C)
  • Float : 13.6V~13.8V(-18mV/°C)
