• Nominal Voltage : 12V
• Rated Capacity (20hr Rate) : 40Ah
• Dimensions
• Length : 7.72" (196mm)
• Width : 6.54" (166mm)
• Height : 6.61" (168mm)
• Total Height : 6.67" (177mm)
• Weight : Approx. 27.56lbs (12.5kg)

Characteristics

• Capacity 77°F(25°C)
• 20hour rate (2.00 A) : 40.0Ah
• 10hour rate (3.60 A) : 36.8Ah
• 5hour rate (6.80 A) : 34.0Ah
• 1hour rate (26.0 A) : 26.0Ah
• Internal Resistance
• Full Charged, 77°F(25°C) : 7mΩ
• Affected By Temperature (10hr Rate)
• 104°F(40°C) : 102%
• 77°F(25°C) : 100%
• 32°F(0°C) : 85%
• 5°F(-15°C) : 65%
• Self-Discharge 77°F(25°C)
• Capacity after 3 month storage : 90%
• Capacity after 6 month storage : 80%
• Capacity after 9 month storag : 60%

Charge (Constant Voltage)

• Initial Charge Current “LESS” than 12.0A
• Cycle : 14.4–15.0V/77°F(25°C)
• Stand By : 13.5–13.8V/77°F(25°C)
