• Nominal Voltage : 12 V
• Design Life : 3-5years
• Norminal Capacity (25°C) 20hours rate : 26 Ah
• Internal Resistance (25°C) : 9 mΩ
• Self Discharge : 3% capacity per month 25°C

Operating Temparature Range

• Discharge : -15~50°C
• Charge : -10~50°C
• Storage : -20~50°C

Charge Method: Constant Voltage (25°C)

• Cycle Mode (14,4÷15 V)
  • Maximum Dischsrge Current : 7.8A
  • Temperature Correction Factor : 15 mV/°C
• Standby Mode (13,62~13,8V)
  • emperature Correction Factor : 10 mV/°C

Dimensions (±2mm)

• Length, mm : 166
• Height over terminals, mm : 175
• Height, mm : 125
• Width, mm : 125
