• Integrated MPPT charge controller
• It can work with battery or without battery
• Maximun PV input voltage up to 450VDC
• Configurable grid or solar input priority
• Optional WIFI/ GPRS remote monitoring
• Parallel for scalability
• Use BATT 48V100A LI-ION GRW battery

• Battery voltage : 48VDC
• Rated Power : 5000VA/ 5000W
• Parallel Capability : Yes, 6 units
• AC Voltage Regulation (Battery Mode) : 230VAC ± 5% @ 50/60Hz
• Surge Power : 10000VA
• Efficiency (Peak) : 93%
• Waveform : Pure sine wave
• Transfer Time : 10 ms (For Personal Computers); 20 ms (For Home Appliances)

Solar Charger

• Maximum PV Array Power : 5500W
• MPPT Range @ Operating Voltage : 120VDC ~ 430VDC
• Maximum PV Array Open Circuit Voltage : 450VDC
• Maximum Efficiency : 100A
• Maximum Solar Charge Current : 97%

AC Charger

• Charge Current : 80A
• AC Input Voltage : 230 VAC
• Selectable Voltage Range : 170-280 VAC (For Personal Computers) ; 90-280 VAC (For Home Appliances)
• Frequency Range : 50Hz/60Hz (Auto sensing)

Physical

• Dimension (D/W/H) in mm : 485/330/135
• Net Weight (kgs) : 12

Operating Environment

• Humidity : 5% to 95% Relative Humidity(Non-condensing)
• Operating Temperature : 0°C - 55°C
• Storage Temperature : -15°C - 60°C

1. Datasheet - GRW SPF5000ES
