Camera

• Image Sensor : 1/2.7" Progressive Scan CMOS
• Max. Resolution : 1920 × 1080
• Min. Illumination : Color: 0.01 Lux @(F2.0, AGC ON), B/W: 0 Lux with IR
• Shutter Time : 1/3 s to 1/100, 000 s
• Day & Night : IR cut filter
• Angle Adjustment : Pan: 0° to 355°, tilt: 0° to 75°

Lens

• Lens Type : Fixed focal lens, 2.8mm
• Focal Length & FOV : 2.8 mm, horizontal FOV 112.1°, vertical FOV 60.0°, diagonal FOV 132.2°
• Lens Mount : M12
• Iris Type : Fixed
• Aperture : F2.0

Illuminator

• Supplement Light Type : IR
• Supplement Light Range : Up to 30 m
• Smart Supplement Light : Yes
• IR Wavelength : 850 nm

Video

• Main Stream
• 50 Hz: 25 fps (1920 × 1080, 1280 × 720)
• 60 Hz: 30 fps (1920 × 1080, 1280 × 720)
• Sub-Stream
• 50 Hz: 25 fps (640 × 480, 640 × 360)
• 60 Hz: 30 fps (640 × 480, 640 × 360)
• Video Compression
• Main stream: H.265/H.264/H.264+/H.265+
• Sub-stream: H.265/H.264/MJPEG
• Video Bit Rate32 Kbps to 8 Mbps
• H.264 TypeBaseline Profile/Main Profile/High Profile
• H.265 Type : Main Profile
• Region of Interest (ROI) : 1 fixed region for main stream

Network

• Protocols : TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP™, SMTP, IGMP, QoS, IPv6, Bonjour, IPv4, UDP, SSL/TLS
• Simultaneous Live View : Up to 6 channels
• AP : IOpen Network Video Interface, ISAPI
• User/Host : Up to 32 users. 3 levels: administrator, operator and user
• Client : iVMS-4200, Hik-Connect
• Web Browser
• Plug-in required live view: IE 10+
• Plug-in free live view: Chrome 57.0+, Firefox 52.0+
• Local service: Chrome 57.0+, Firefox 52.0+


• Image Settings : Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser.
• Day/Night Switch : Day, Night, Auto, Schedule
• Wide Dynamic Range (WDR) : Digital WDR
• Image Enhancement : BLC, 3D DNR

Interface

• Ethernet Interface : 1 RJ45 10 M/100 M self-adaptive Ethernet port

Event

• Basic Event : Motion detection, video tampering alarm, exception
• Linkage : Upload to FTP, notify surveillance center, send email

General

• Power
• 12 VDC ± 25%, 0.4 A, max. 5 W, Ø5.5 mm coaxial power plug
• PoE: 802.3af, Class 3, 36 V to 57 V, 0.2 A to 0.15 A, max. 6.5 W
• DimensionØ : 111 mm × 82.4 mm (Ø4.4" × 3.2")
• Package Dimension : 134 mm × 134 mm × 108 mm (5.3" × 5.3" × 4.3")
• Weight : Approx. 410 g (0.9 lb.)
• With Package Weight : Approx. 610 g (1.3 lb.)
• Storage Conditions : -30 °C to 60 °C (-22 °F to 140 °F). Humidity: 95% or less (non-condensing)
• Startup and Operating Conditions : -30 °C to 60 °C (-22 °F to 140 °F). Humidity: 95% or less (non-condensing)
• General Function : Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter
