• 3.97-inch LCD touch screen for face enrollment, parameters configuration, live view, etc.
• 2 MP wide-angle dual-lens
• Face anti-spoofing, Face enrollment distance: 0.3 m to 1.5 m
• Deep learning algorithm
• 2,000 user capacity, 2,000 face capacity, 20,000 card capacity, and 20,000 fingerprint capacity
• Enrolls data via the device and transmits the data from the device to the platform via TCP/IP/Type C USB interface; Enrolls data remotely via the client software
• Stand-alone operation: Manage, search and set device data after logging in the device locally

System

• Operating system : Linux

Display

• Screen size : 3.97-inch
• Operation method : Touch
• Type : Capacitive
• Resolution : 800 × 480

Video

• Lens : 2
• Resolution : 2 MP
• WDR : Support

Network

• Wired network : TCP/IP
• Wi-Fi : Support, 2.4 G, 802.11b/g/n

Interface

• USB : Supports 1 USB interface and 1 Type C USB interface (Type C USB interface is used for communicating with the platform.)

Capacity

• User capacity : 2000
• Face capacity : 2000
• Fingerprint capacity : 20,000 (10 fingerprints per person)
• Card capacity : 20,000 (The displayed capacity on the device screen varies according to the configured enrollment rules)
• Event capacity : 2000 offline enrollment records

Authentication

• Face recognition distance : 0.3 m to 1.5 m
• Card type : EM card;M1 card;DESfire card;Felica card
• Card reading frequency : 13.56MHz, 125KHz
• Card reading distance : 0 to 5 cm

General

• Power supply : 12 VDC, 15 W, Round
• Working temperature : -10 °C to 50 °C (14 °F to 122 °F)
• Working humidity : 10％ to 90％
• Dimensions : 121.6 mm × 137.9 mm × 125 mm (4.8" × 5.4" × 4.9")
• Installation : Base mounting
• Application environment : Indoor

Function

• Face anti-spoofing : Support
• Audio prompt : Support
• Time synchronization : Support
