GRW SPF5000TL HVM-P
Growatt Pure Sine Wave Inverter 5000VA/5000W, 48VDC, O/P:230VAC Max PV:4500W, MPPT Voltage :60-115VDC, Max PV OCV:145VDC, Max Solar Charge Current:80A, AC CHARGE CURRENT:60A, Surge PWR:10000VA, (130x350x455mm) 11.5kg

Name: GRW SPF5000TL HVM-P - Communica [Part No: GRW SPF5000TL HVM-P]
Brand: Growatt
SKU: GRW SPF5000TL HVM-P
Price: 12350 ZAR
Availability: OutOfStock

SKU: GRW SPF5000TL HVM-P

BRAND: Growatt

Sold Out
R 14,202.50_{(inc VAT)}
R 12,350.00_{(ex VAT)}

Or split into 4x interest-free
payments Learn more

Collections: Loadshedding, Power

Type: Power Inverters

Category: Loadshedding, Pure Sine Wave Inverters

Pure Sine Wave Inverter 5000VA/5000W

Overview

Growatt SPF 3000-5000TL HVM series off grid solar inverter is integrated with a MPPT solar charge controller, Transformerless design provides reliable power conversion in compact size.

Feature

Integrated MPPT charge controller
Configurable grid or solar input priority
WIFI remote monitoring
Parallel for scalability

Specifications

Inverter Output

Waveform: Pure Sine-Wave
Rated Power: 5000VA/5000W
Parallel Capability: Yes, 6 units
AC Voltage Regulation (Battery Mode): 230VAC ± 5% @ 50/60Hz
Surge Power: 10000VA
Efficiency (Peak): 93%
Transfer Time: 10 ms (For Personal Computers); 20 ms (For Home Appliances)

Solar Charger

Maximum PV Array Power: 4500W
MPPT Range @ Operating Voltage: 60VDC ~115VDC
Standby Power Consumption: 2W
Maximum PV Array Open Circuit Voltage: 145VDC
Maximum Efficiency: 97%
Maximum Solar Charge Current: 80A

AC Charger

Charge Current: 60A
AC Input Voltage: 230 VAC
Selectable Voltage Range: 170-280 VAC (For Personal Computers); 90-280 VAC (For Home Appliances)
Frequency Range: 50Hz/60Hz (Auto sensing)

Physical

Dimension (D/W/H) in mm: 130*350*455
Net Weight (kgs): 14.5

Downloads

Datasheet - GRW SPF5000TL HVM-P

Additional Information

Device	Inverter
Type	Pure Sine Wave \| 5000VA/5000W
