Camera

• Pixel : 2 MP
• Image Sensor : 2 MP CMOS
• Max. Resolution : 1920 (H) × 1080 (V)
• Scanning System : Progressive
• Electronic Shutter Speed
  • PAL: 1/25 s–1/100,000 s
  • NTSC: 1/30 s–1/100,000 s
• Min. Illumination
  • 0.001 lux@F1.6 (Color, 30 IRE)
  • 0.0001 lux@F1.6 (B/W, 30 IRE)
  • 0 lux (Illuminator on)
• S/N Ratio : >65 dB
• Illumination Distance
  • IR: 40 m (131.23 ft)
  • Warm light: 40 m (131.23 ft)
• Illuminator On/Off Control : Auto/Manual
• Illuminator Number
  • 2 (IR light)
  • 2 (Warm light)
• Pan/Tilt/Rotation Range
  • Pan: 0°–360°
  • Tilt: 0°–90°
  • Rotation: 0°–360°

Lens

• Lens Type : Fixed-focal
• Lens Mount : M12
• Focal Length : 3.6 mm
• Max. Aperture : F1.6
• Field of View : 3.6 mm: H: 86°; V: 46°; D: 101°
• Iris Control : Fixed
• Close Focus Distance: 3.6 mm: 1.1 m (3.61 ft)

Video

• Video Frame Rate

  • CVI:
  • PAL: 1080p@25 fps;
  • NTSC: 1080p@30 fps;
  • AHD:
  • PAL: 1080p@25 fps;
  • NTSC: 1080p@30 fps;
  • TVI:
  • PAL: 1080p@25 fps;
  • NTSC: 1080p@30 fps;
  • CVBS:
  • PAL: 960 × 576H;
  • NTSC: 960 × 480H
• Resolution : 1080p (1920 × 1080); 960H (960 × 576/960 × 480)
• Day/Night : Auto (ICR)/Color/B/W
• BLC : BLC; HLC; WDR
• WDR : 130 dB
• White Balance : Auto; Area white balance
• Gain Control : Auto/Manual
• Noise Reduction : 3D NR
• Smart Illumination : Yes
• Mirror : Off/On
• Privacy Masking : Off/On (8 areas, rectangle)
• Illuminator : Smart IR&WL; WL Mode; IR Mode

1. Datasheet - DHA HAC-HFW1239TLMP-IL-A 3.6MM
