Camera
|
|
Image Sensor
|
2 MP CMOS
|
|
Max. Resolution
|
1920 (H) × 1080 (V)
|
|
Scanning System
|
Progressive
|
|
Electronic Shutter Speed
|
PAL: 1/25 s–1/100000 s
NTSC: 1/30 s–1/100000 s
|
|
Min. Illumination
|
0.01 lux@F1.6 (Color, 30 IRE)
0.001 lux@F1.6 (B/W, 30 IRE)
0 lux (Illuminator on)
|
|
S/N Ratio
|
>65 dB
|
|
Illumination Distance
|
60 m (196.85 ft)
|
|
Illuminator On/Off Control
|
Auto
|
|
Illuminator Number
|
3 (IR light)
|
|
Angle Adjustment
|
Pan: 0°–355°
Tilt: 0°–80°
Rotation: 0°–355°
|
|
Lens
|
|
Lens Type
|
Motorized Vari-focal
|
|
Auto Focus
|
No
|
|
Lens Mount
|
φ14
|
|
Focal Length
|
2.7 mm–12 mm
|
|
Max. Aperture
|
F1.6
|
|
Field of View
|
H: 28.3°–98.2°; V: 15.8°–51.9°; D: 32.1°–116.7°
|
|
Iris Control
|
Fixed
|
|
Close Focus Distance
|
0.8 m (2.62 ft)
|
|
DORI Distance
|
Lens
|
Detect
|
Observe
|
Recognize
|
Identify
|
|
2.7 mm
|
47.4 m
(155.51 ft)
|
18.9 m
(62.01 ft)
|
9.5 m
(31.17 ft)
|
4.7 m
(15.42 ft)
|
|
12 mm
|
155.6 m
(510.50 ft)
|
62.2 m
(204.07 ft)
|
31.1 m
(102.03 ft)
|
15.6 m
(51.18 ft)
|
|
Video
|
|
Video Frame Rate
|
CVI:
PAL: 1080p@25 fps;
NTSC: 1080p@30 fps;
AHD:
PAL: 1080p@25 fps;
NTSC: 1080p@30 fps;
TVI:
PAL: 1080p@25 fps;
NTSC: 1080p@30 fps;
CVBS:
PAL: 960H;
NTSC: 960H
|
|
Resolution
|
1080p (1920 × 1080); 960H (960 × 576/960 × 480)
|
|
Day/Night
|
Auto(ICR)/Color/B/W
|
|
BLC
|
BLC; HLC; DWDR
|
|
WDR
|
DWDR
|
|
White Balance
|
Auto;Area white balance
|
|
Gain Control
|
Auto
|
|
Noise Reduction
|
3D NR
|
|
Illumination Mode
|
Smart IR
|
|
Mirror
|
Yes
|
|
Privacy Masking
|
Off/On (8 areas, rectangle)
|
|
Certification
|
|
Certifications
|
CE-LVD: EN 62368-1;
CE-EMC: EN 55032; EN 55035;
FCC: 47 CFR FCC Part 15, Subpart B;
UL: UL62368-1 + CAN/CSA C22.2 No. 62368-1-14
|
|
Port
|
|
Video Output
|
Video output choices of CVI/TVI/AHD/CVBS by one BNC port
|
|
Audio Input
|
One channel built-in Mic
|
|
Power
|
|
Power Supply
|
24 VAC ± 30%;12 VDC ± 10%
|
|
Power Consumption
|
Max 7.3 W (12 VDC, IR on)
|
|
Environment
|
|
Operating Temperature
|
–30 °C to +60 °C (–22 °F to +140 °F)
|
|
Operating Humidity
|
<95% (RH), non-condensing
|
|
Storage Temperature
|
–30 °C to +60 °C (–22 °F to +140 °F)
|
|
Storage Humidity
|
<95% (RH), non-condensing
|
|
Protection
|
IK10;IP67
|
|
Anti-corrosion Level
|
Basic Protection
|
|
Structure
|
|
Casing Material
|
Metal
|
|
Product Dimensions
|
φ126 mm × 100 mm (φ4.96" × 3.94")
|
|
Net Weight
|
0.65 kg (1.43 lb)
|
|
Gross Weight
|
0.83 kg (1.83 Ib)
|
|
Installation
|
Wall mount; ceiling mount; vertical pole mount
|
