OPEN AND CLOSE THE GATE FROM ANYWHERE IN THE WORLD. gateBoxPro is an upgraded version of the gateBox controller with an extended range and increased water resistance class; the controller allows you to open and close the gates from any place in the world, and what’s more, to check their status by using a smartphone or tablet, without the need of purchasing an additional equipment or paying hidden fees.
- Supply voltage : 12-24V AC / DC
- Power consumption : less than 1W
- Outputs number : 2
- Outputs type : vopen colector
- Maximum current channel : 20mA
- Inputs number : 2
- Inputs type : logical, voltage
- Inputs voltage : 12 – 24V AC / DC
- Galvanic isolation : Yes, optical
- Inputs polarization : detected automatically
- Housing : made of polyurethane composition not containing halogens, self-extinguishing for thermal class B (130 °C)
- Protection Rating : IP20
- Transmission : bi-directional, encrypted
- Transmission frequency : 2.4GHz
- Communication standard : μWiFi, compatible with WiFi
- Communication mode : direct connection (as access point), Wi-Fi connection via a standard router, connection with access from any location in the world (requires access to the Internet)
- Control with : Apple iPhone, Apple iPad, iPad Mini, Android, computers and mobile devices operating a fully HTML5
- Encryption : WPA2-PSK and authenticated encryption with associated data (AEAD)
