• Nominal Voltage : 12V
• Rated Capacity 77°F(25°C (20hr Rate) : 1.3Ah
• Dimensions (mm/inch)
• Length : 97 (3.82)
• Width : 43 (1.69)
• Height : 52 (2.05)
• Total Height : 58 (2.28)
• Approx. Weight (kg/Ibs) : 0.6 (1.32)
• Terminal : T1

Characteristics

• Capacity 77°F(25°C)
• 20hour rate (0.60 A) : 1.30 Ah
• 10hour rate (0.112 A) : 1.12 Ah
• 5hour rate (0.204 A) : 1.02 Ah
• 1hour rate (0.732 A) : 0.73 Ah
• 15 min rate (22.2A) : 0.56Ah
• Internal Resistance
• Full Charged, 77°F(25°C) : Approx.85mΩ
• Temperature dependence of capacity (20HR)
• 104°F(40°C) : 102%
• 77°F(25°C) : 100%
• 32°F(0°C) : 85%
• 5°F(-15°C) : 65%
• Self-Discharge 68°F(20°C) (Capacity after)
• Capacity after 3 month storage : 90%
• Capacity after 6 month storage : 80%
• Capacity after 12 month storag : 60%
• Max. Discharge Current, 77°F(25°C) : 18A(5s)
• Floating design life, 77°F(25°C) : 5 years
• Constant Voltage Charge, 77°F(25°C)
• Cycle : 14.5~7.14.9V(-24mV/°C) max. current:0.36 A)
• Float : 13.6~13.8V(-18mV/°C)

1. Datasheet - BATT 12V1,3 VTX
