ADVANTAGES AT A GLANCE

Powerful, user friendlyand cost-efficient

• Powerful with 70 W – gets your soldering job done faster
• Easy to handle high performance iron
• Intuitive navigation
• Low total cost of ownership

Maximum reliability and protection

• ESD safe station, iron, and heat-resistant silicon cable for safe handling
• Reinforced safety rest for secure iron storage
• Temperature stability (+/- 4°F, 2°C ) and temperature lock protects tips and components, affording a consistently high quality process with repeatable soldering results
• Standby mode and auto setback conserves energy, protects equipment
• Password-protected to preserve settings

• Dimensions L x W x H 150 x 125 x 100 mm 5.91 x 4.92 x 3.94 inches
• Power supply 230 V / 50 Hz; 120 V / 60 Hz
• Power 70 W
• Temperature range 200°F–850°F; 100°C – 450°C
• Temperature accuracy +/- 17°F , 9°C
• Temperature stability +/- 4°F , 2°C
• ESD safe yes
• Supplied tip ETA

Accessories

• T0058770714 WEP70 TIP RETAINER
• T0058770715 WEP70 SOLDERING IRON
• T0058770706 PH70 SAFETY REST WITH SPONGE
• TC205 SPONGE REPLACEMENT
• ET SERIES TIPS
