component testing for Cat.6A to ISO/IEC 11801 Ed.2.2:2011-06, DIN EN 50173-1:2011-09, TIA/EIA-568-C.2 (2009-08) and IEC 60603-7-51 Ed.1 (12/2008), certified to GHMT
compliance with class EA to ISO/IEC 11801
Ed.2.2:2011-06, DIN EN 50173-1:2011-09
tested: Link up to 500 MHz
suitable for 10 GBit Ethernet (IEEE 802.3an), Remote Powering (PoE, PoE plus, UPoE and 4PPoE) and HDBaseT
easy to install connection of 2 to 4 pair data cables
AWG 26/1 to 22/1 (solid wire) and stranded wires with 7 copper conductors AWG 26/7 to 22/7 to insulation displacement connectors (IDC)
marking of conductor assignment to T568A and T568B
easy and fast insertion of wire pairs in E-DAT modul stuffer cap
