• Channel : 2
• Max frequency : 30MHz
• Sampling rate : 200MS/s
• Vertical resolution : 14 bits
• Waveforms : Sine, square, pulse, ramp, noise, DC, arbitrary
• Sweep modes : Logarithmic, linear

Frequency Characteristics

• Sine : 1μHz~30MHz
• Square : 1μHz~15MHz
• Ramp : 1μHz~400kHz
• Pulse : 1μHz~15MHz
• Arbitrary : 1μHz~10MHz
• Resolution : 1μHz
• Accuracy

  • Within 90 days ± 50ppm
  • Within 1 year ± 100ppm
  • 18℃~28℃

Output Characteristics

• Impedance : 50Ω/High Z
• Amplitude range : 1mVpp~10Vpp (50Ω); 2mVpp~20Vpp (high Z)
• DC offset range (AC+DC) : ±5V (50Ω); ±10V  (high Z)
• Amplitude resolution : 1mV

General Characterisitics

• Power : 100~240VAC, 50Hz/60Hz
• Display : 4.3”TFT LCD (480×272)
• Product color : White and grey
• Product net weight : 0.33kg
• Product size : 172mm x 90mm x 68mm
• Standard accessories : USB interface cable, power cord, BNC cable with alligator clips
• Standard individual packing : Carton box
• Standard carton measurement : 435mm x 360mm x 125mm
• Standard carton gross weight : 3.8kg

1. Datasheet - UNI-T UTG932E
