• Universal 2.5mm bulkhead
• Compatible with single mode and multimode fibres
• 2Hz modulation mode
• Operating temperature ranges between -10°C and 45°C
• Long battery life of 80 hours with 3.9Wh batteries
• Red/Green LEDs for display operations

Applications

• Measure and locate high-loss splices, connections and breaks
• Locate the end of a fibre
• Find potential sources of error caused by reflectance from dirty or poor connections
• Detect live optical signals before it begins testing

Certifications

• CE certified
• CDRH certified
• Class 2 certification provides safe light levels to the technician

• Cable Type : Single Mode & Multimode
• Wavelengths : 650nm
• Operation Test Distance : 7km
• Battery Type : AA
• Battery Life : 80 h
• Power Source : Battery
• Includes : Visual Fault Locator, AA Batteries (2), Instruction Manual, Soft Carry Case
• Minimum Operating Temperature : -10°C
• Dimensions : 23 (Dia.) x 180mm
• Maximum Operating Temperature : +45°C
• Diameter : 23mm
• Weight : 120 (with out Battery)g
• Height : 180mm
