• High sensitivity thermal module with 160 x 120 resolution
• NETD < 35 mK (@25 ° C F#=1.1)
• Leading thermal image processing technology: Adaptive AGC, DDE, 3D DNR
• 720 × 540 resolution 0.2-inch LCOS display
• Built-in rechargeable lithium battery
• Up to 10 hours continuous operation
• Wi-Fi hot spot
• Type-C Interface

Thermal Module

• Image Sensor : VOx Uncooled Focal Plane Arrays
• Resolution : 160 × 120
• Frame Frequency : 50 Hz
• Pixel Interval : 17 μm
• Response Waveband : 8 μm to 14 μm
• NETD : ≤ 35 mK (@25°C),F#=1.1
• Focal Length : 6.2 mm
• IFOV : 2.74 mrad
• Field of View : 24.7° × 18.7° (H × V)
• Aperture : F1.1

Image Display

• Monitor : 0.2 inch, LCOS, 720 × 540
• Palettes : Black Hot, White Hot, Red Hot, Fusion
• FFC (Flat Field Correction) Mode : Auto, Manual, External Correction
• Digital Zoom : 1 ×, 2 ×, 4 ×

Smart Function

• Hot Track : Yes
• Detection Range : 219 m

System

• Storage : Built-in memory module (8 GB)
• Record Video : Yes
• Capture Snapshot : Yes
• Wi-Fi : Yes
• Standby Mode : Yes

Power Supply

• Battery Type : Rechargeable Lithium Battery
• Battery Operating Time
  • 10 hours continuous running with CVBS and Wi-Fi hot spot off (@25°C)
  • 7.5 hours continuous running with CVBS and Wi-Fi hot spot on (@25°C)
• Battery Capacity Display : Yes

General

• Power : 5 VDC/2 A, 1.5 W, Type-C Interface
• Work Temperature/Humidity : From -20 °C to 55 °C (-4 °F to 131 °F); Humidity: 90% or Less
• Protection Level : IP67
• Dimension : 158.3 mm × 61 mm × 57 mm (6.23" × 2.40" × 2.24")
• Weight : 250 g (0.55 lb)

1. Datasheet - HKV HM-TS01-06XF/W-LC06
