• Nominal Voltage : 12V
• Rated Capacity (20hr Rate) : 9Ah
• Dimensions
• Length : 151mm
• Width : 65mm
• Height : 94mm
• Total Height : 100mm
• Weight : 3.46kg

Characteristics

• Capacity 77°F(25°C)
• 20hour rate (0.45 A) : 9.0Ah
• 10hour rate (0.83 A) : 8.3Ah
• 5hour rate (1.53 A) : 7.7Ah
• 1hour rate (5.85 A) : 5.9Ah
• Internal Resistance
• Full Charged, 77°F(25°C) : 25mΩ
• Affected By Temperature (10hr Rate)
• 104°F(40°C) : 102%
• 77°F(25°C) : 100%
• 32°F(0°C) : 85%
• 5°F(-15°C) : 65%
• Self-Discharge 77°F(25°C)
• Capacity after 3 month storage : 90%
• Capacity after 6 month storage : 80%
• Capacity after 9 month storag : 60%

Charge (Constant Voltage)

• Initial Charge Current “LESS” than 3.6A
• Cycle : 14.4–15.0V/77°F(25°C)
• Stand By : 13.5–13.8V/77°F(25°C)
